The Teledyne FLIR VUE-PRO-R-640-19MM-9HZ Radiometric Thermal Imager equips drone operators and certified thermographers with a powerful tool for precise, non-contact temperature measurement from above. Designed for use with small unmanned aerial systems (sUAS), this imager captures calibrated temperature data in every pixel of each still image, ensuring accurate radiometric analysis across various applications.
With a 19mm lens and 640 x 512 resolution, the VUE-PRO-R delivers high-fidelity thermal imagery suitable for a range of critical tasks such as infrastructure inspections, precision agriculture, utility inspections, and public safety missions. Its user-friendly interface, onboard recording capabilities, and compatibility with MAVLink and Teledyne FLIR software make it a versatile and valuable addition to any commercial drone toolkit.
What's Included:
- 1 - Radiometric Thermal Imager for Drones (sUAS) with 19mm Lens, 640 x 512, 9 Hz
- 1 - Bench Cable
- 1 - MicroSD Card
- 1 - Accessory Cable
Features
High-Resolution Thermal Sensor
Equipped with a 640 x 512 uncooled VOx Microbolometer sensor for crisp thermal imagery.
Optimized for Airborne Use
Image settings are fine-tuned for drone-based applications, providing clarity and contrast from aerial views.
Radiometric Imaging
Every still image includes accurate temperature data embedded in each pixel for post-flight analysis.
Flexible Storage Options
Records video in MOV format and saves stills as radiometric JPEG or 14-bit TIFF formats directly to a microSD card.
Multiple Frame Rates
Supports 7.5 Hz for NTSC and 8.3 Hz for PAL for compatibility with global standards.
Wide Field of View
The 19mm lens provides a 32° x 26° FOV (32° x 24° for NTSC analog output), ideal for broad area scans.
Simple Integration
Uses a 10-pin mini-USB connector for power and analog video output, streamlining setup.
Advanced Control Options
Compatible with PWM controls to adjust settings like color palettes and zoom in real-time.
MAVLink Compatibility
Integrates with MAVLink-enabled flight controllers for automated camera control.
Mobile App Configuration
Configure recording and operational settings easily through Teledyne FLIR’s UAS mobile app.
Post-Flight Analysis Support
Compatible with Teledyne FLIR Tools for detailed thermal analysis and reporting.
Accurate Temperature Measurement
Offers ±5°C or 5% measurement accuracy for reliable thermal diagnostics.
Field-Upgradeable Firmware
Ensures long-term value and adaptability to evolving mission needs.
What's Included
Included with Your Purchase:
- 1 - Radiometric Thermal Imager for Drones (sUAS) with 19mm Lens, 640 x 512, 9 Hz
- 1 - Bench Cable
- 1 - MicroSD Card
- 1 - Accessory Cable
Specifications
-
Sensor Resolution: 640 x 512
-
Lens: 19mm
-
Field of View: 32° x 26° (digital); 32° x 24° (NTSC analog)
-
Frame Rate: 7.5 Hz (NTSC); 8.3 Hz (PAL)
-
Spectral Band: 7.5 µm to 13.5 µm
-
Imager Type: Uncooled VOx Microbolometer
-
Temperature Accuracy: ±5°C or 5% of reading
-
Output Interface: Power-in/analog video-out via 10-pin mini-USB
-
Image File Formats: Radiometric JPEG, 14-bit TIFF
-
Video Format: MOV
-
Control Options: PWM input, MAVLink integration, UAS mobile app
-
Software Compatibility: Teledyne FLIR Tools
-
Firmware: Field-upgradeable
FAQ
Q: What type of thermal sensor is used in the VUE-PRO-R-640-19MM-9HZ?
A: It uses an uncooled VOx Microbolometer for high-resolution thermal imaging.
Q: Can I store both videos and still images on this camera?
A: Yes, the camera records video in MOV format and saves still images as radiometric JPEGs or 14-bit TIFFs to a microSD card.
Q: What level of temperature accuracy does it offer?
A: It provides temperature readings accurate to ±5°C or 5% of the reading.
Q: Is this thermal imager compatible with MAVLink-enabled drones?
A: Yes, it integrates fully with MAVLink for automated flight and camera control.
Q: How do I configure the camera settings?
A: Settings can be adjusted via PWM input or Teledyne FLIR’s UAS mobile app.
