The Extech 475044 High Capacity Force Gauge is engineered for precision and reliability, making it ideal for industrial force measurement tasks. With the ability to measure push and pull forces up to 196 Newtons (44.1 lbs or 20 kg), it offers versatile performance in quality control, manufacturing, and R&D environments.
Its high-contrast 5-digit LCD screen includes a reversible display, enhancing visibility from various angles. The gauge features both fast and slow response modes, enabling users to tailor data collection to specific testing needs. The exclusive load cell measurement transducer ensures consistent accuracy, supported by a basic accuracy rating of 0.5%.
Peak hold functionality captures the highest force applied during a test, while intuitive indicators warn users of overrange and low battery. Additional functions like zero adjust and an advanced feature indicator streamline operation. Built for both portability and durability, the Extech 475044 is a compact and dependable solution for professionals requiring high-capacity force measurements.
What's Included:
- 1 - Tension Rod
- 1 - Carrying Case 4 Adapters
- 1 - Flathead
- 1 - Cone
- 1 - Chisel Hook For Tension
- 6 - AA Batteries
Features
Multi-Unit Measurement Display
Provides push/pull readings in kilograms, pounds, ounces, and Newtons on a crisp 5-digit LCD screen.
Reversible Display
The LCD orientation can be flipped for optimal viewing in various test setups and angles.
Peak Hold and Fast/Slow Modes
Capture maximum force with peak hold and choose between fast or slow response for measurement control.
Exclusive Load Cell Transducer
Ensures precise force detection with long-term reliability.
Status Indicators
Includes visual alerts for overrange, low battery, and advanced mode selection.
Zero Adjust and Advanced Controls
Features a simple push-button zeroing and an advanced function switch for enhanced usability.
What's Included
Included with Your Purchase:
- 1 - Tension Rod
- 1 - Carrying Case 4 Adapters
- 1 - Flathead
- 1 - Cone
- 1 - Chisel Hook For Tension
- 6 - AA Batteries
Specifications
-
Measurement Capacity: 20 kg / 44.1 lbs / 196.1 Newtons
-
Display: 5-digit reversible LCD
-
Accuracy: ±0.5%
-
Measurement Units: kg, lbs, oz, Newtons
-
Response Modes: Fast and Slow
-
Indicators: Overrange, Low Battery, Advanced Function
-
Functions: Peak Hold, Zero Adjust
-
Power: 6 x AA Batteries
-
Model Number: 475044
-
Condition: New
-
UPC: 793950470442
FAQ
Q: What is the maximum force this gauge can measure?
A: The Extech 475044 can measure up to 196.1 Newtons, 44.1 lbs, or 20 kg.
Q: Does this device have a peak hold feature?
A: Yes, it includes a peak hold function that records the highest force applied.
Q: Can the screen orientation be changed?
A: Yes, the LCD display can be reversed for easy viewing from different angles.
Q: What power source does the unit use?
A: It operates on 6 AA batteries, which are included.
Resources
