The Teledyne FLIR VUE-PRO-R-336-9MM-9HZ Radiometric Thermal Imager is designed for professional drone (sUAS) operators who require precise, non-contact temperature measurement from the air. With a 336 x 256 resolution and 9mm lens, this compact sensor delivers calibrated temperature data embedded into every pixel of each saved image. It supports accurate radiometric imaging for tasks such as infrastructure inspections, public safety operations, agricultural analysis, and more.
Built with advanced VOx microbolometer technology and optimized for airborne applications, the VUE-PRO-R seamlessly integrates with MAVLink-enabled flight control systems. Users can adjust color palettes, zoom, and other camera settings via PWM inputs, while recording thermal video or stills to an onboard microSD card. Compatible with Teledyne FLIR’s software suite, it allows full post-flight analysis and configuration through mobile or desktop applications.
What's Included:
- 1 - Radiometric Thermal Imager for Drones (sUAS) with 9mm Lens, 336 x 256, 9 Hz
- 1 - Bench Cable
- 1 - MicroSD Card
- 1 - Accessory Cable
Features
Radiometric Imaging Capability
Captures still images with embedded, calibrated temperature data in every pixel for in-depth thermal analysis.
Thermal Sensor Resolution
Features a 336 x 256 resolution for high-quality thermal imaging at 9 Hz frame rate.
Wide Field of View
9mm lens provides a 35° x 27° field of view, ideal for aerial coverage and situational awareness.
Accurate Temperature Measurements
Offers ±5°C or 5% of reading accuracy, ensuring reliability in critical inspections.
Simple Integration
10-pin mini-USB provides streamlined power and analog video output for efficient onboard installation.
Video and Image Recording
Record real-time thermal videos in MOV format and save stills as Radiometric JPEGs or 14-bit TIFFs.
MAVLink Compatibility
Integrates with MAVLink for in-flight camera control and telemetry from compatible flight controllers.
PWM Camera Control
Use PWM inputs to remotely control camera features including color palette selection and digital zoom.
Software and App Integration
Works with FLIR Tools and the Teledyne FLIR UAS mobile app for post-flight analysis, configuration, and reporting.
Optimized for Airborne Use
Designed specifically for drone applications with lightweight construction and image settings tailored for flight.
Expandable and Upgradeable
Field-upgradeable firmware allows you to maintain cutting-edge performance and compatibility.
What's Included
Included with Your Purchase:
- 1 - Radiometric Thermal Imager for Drones (sUAS) with 9mm Lens, 336 x 256, 9 Hz
- 1 - Bench Cable
- 1 - MicroSD Card
- 1 - Accessory Cable
Specifications
-
Sensor Resolution: 336 x 256
-
Lens: 9mm
-
Field of View: 35° x 27° (NTSC); 34° x 26° for analog output
-
Frame Rate: 7.5 Hz (NTSC); 8.3 Hz (PAL)
-
Spectral Band: 7.5 µm to 13.5 µm
-
Sensor Type: Uncooled VOx Microbolometer
-
Measurement Accuracy: ±5°C or 5% of reading
-
Video Output: Analog via 10-pin mini-USB
-
Image Formats: Radiometric JPEG, 14-bit TIFF
-
Video Format: MOV
-
Interface Options: MAVLink, PWM Inputs
-
Software Compatibility: Teledyne FLIR Tools, UAS App
-
Upgradeability: Field-upgradeable firmware
-
Product Condition: New
FAQ
Q: What is the resolution of the thermal sensor?
A: The VUE-PRO-R features a 336 x 256 thermal resolution sensor.
Q: Does the camera save temperature data in images?
A: Yes, it saves fully radiometric JPEGs with temperature data embedded in each pixel.
Q: Can the camera be controlled mid-flight?
A: Yes, through MAVLink or PWM inputs, you can adjust settings like zoom and color palette.
Q: What software is compatible with this camera?
A: The camera works with Teledyne FLIR Tools and the UAS mobile app for analysis and configuration.
Q: How is the video output handled?
A: It outputs analog video over a 10-pin mini-USB connector.
