The Teledyne FLIR VUE-PRO-R-640-19MM-30HZ Radiometric Thermal Imager empowers drone operators and certified thermographers with precise, non-contact temperature measurement capabilities from above. Designed specifically for small unmanned aerial systems (sUAS), it captures calibrated temperature data embedded in every pixel of still images, significantly enhancing the value of aerial inspections and surveys.
Whether deployed for building diagnostics, infrastructure monitoring, utility inspections, or agricultural assessment, this high-resolution thermal camera delivers professional-grade imaging with accurate radiometric detail. Its streamlined connectivity, onboard recording, and MAVLink compatibility make it a flexible tool for dynamic field operations.
What's Included:
- 1 - Radiometric Thermal Imager for Drones (sUAS) with 19mm Lens, 640 x 512, 30 Hz
- 1 - Bench Cable
- 1 - MicroSD Card
- 1 - Accessory Cable
Features
High-Resolution Thermal Imaging
Delivers crisp thermal imagery at 640 x 512 resolution, ideal for detailed inspection and analysis.
19mm Lens with Wide Field of View
Offers a 32° x 26° field of view (32° x 24° NTSC) to capture broad scenes from a safe distance.
Real-Time Temperature Sensing
Provides accurate temperature measurements with +/-5°C or 5% of reading precision.
Full Frame Rate Performance
Operates at 30 Hz (NTSC) for fluid video output and detailed frame capture.
Onboard Recording Capabilities
Records thermal images and videos directly to a microSD card in Radiometric JPEG, 14-bit TIFF, or MOV formats.
Advanced Radiometric Functionality
Embeds temperature data in every pixel for comprehensive post-flight analysis.
Airborne Image Optimization
Preset image settings tailored for aerial thermal imaging enhance contrast and detail.
Simple Integration
Utilizes a 10-pin mini-USB interface for power and analog video output.
Flight System Compatibility
Supports MAVLink integration and PWM controls for in-flight adjustments like zoom and color palette changes.
Mobile App and Software Support
Configure recording settings via Teledyne FLIR’s UAS app and analyze data using FLIR Tools software.
Field-Upgradeable Design
Enables future upgrades to extend functionality over time.
What's Included
Included with Your Purchase:
- 1 - Radiometric Thermal Imager for Drones (sUAS) with 19mm Lens, 640 x 512, 30 Hz
- 1 - Bench Cable
- 1 - MicroSD Card
- 1 - Accessory Cable
Specifications
-
Sensor Resolution: 640 x 512
-
Lens: 19mm
-
Field of View: 32° x 26° (digital); 32° x 24° (analog NTSC)
-
Frame Rate: 30 Hz (NTSC); 25 Hz (PAL)
-
Spectral Band: 7.5 µm to 13.5 µm
-
Detector Type: Uncooled VOx Microbolometer
-
Measurement Accuracy: +/-5°C or 5% of reading
-
Interface: 10-pin mini-USB (power and analog video output)
-
Video Format: MOV
-
Still Image Formats: Radiometric JPEG, 14-bit TIFF
-
Embedded Data: Temperature data in every pixel
-
Control Inputs: PWM
-
App Support: Teledyne FLIR UAS mobile app
-
Software Compatibility: Teledyne FLIR Tools
-
Upgradability: Field-upgradeable
FAQ
Q: Can this thermal imager record video onboard?
A: Yes, it records real-time thermal video in MOV format directly to a microSD card.
Q: What image formats does it support?
A: It saves still images as Radiometric JPEG and 14-bit TIFF, both with embedded temperature data.
Q: Is it compatible with MAVLink flight controllers?
A: Yes, it supports MAVLink integration for streamlined communication with compatible systems.
Q: Can the camera be configured in the field?
A: Yes, using Teledyne FLIR’s UAS mobile app, you can adjust recording and control settings on-site.
Q: What kind of drone is this best suited for?
A: It is designed for small unmanned aerial systems (sUAS) that support its power and control interface.
