Extech HDV540 Articulating VideoScope Kit with 6mm Camera & 3.5" Monitor

The Extech HDV540 High-Definition Articulating VideoScope Kit delivers precise visual inspection capabilities with its 6mm flexible camera probe and articulating tip. Designed for professionals needing a detailed view in hard-to-reach areas, this lightweight handheld system offers intuitive one-hand operation and superior image clarity. The 240° articulating camera tip allows users to maneuver around corners and into tight spaces with ease, making it ideal for inspections in automotive, plumbing, or industrial environments.

The 3.5" high-resolution TFT LCD monitor displays crisp images and videos, which can be stored to the included 4GB SD card or transferred via USB. The waterproof camera probe is built for durability and is equipped with four bright LED lamps and a dimmer for glare-free viewing, even in low-light conditions. The system also features AV output for external monitor viewing and voice-over recording for enhanced documentation.

What's Included:

• 1 - Handset with Articulating Probe
• 1 - SD card
• 1 - 3.7V Rechargeable Battery
• 1 - Universal AC adaptor and multi-plugs (US, EU, UK, AUS)
• 1 - USB and AV cables
• 1 - Hard Carrying Case

Features

Articulating Camera Tip
Offers 240° of movement to easily navigate around tight corners and obstructions.

High-Resolution LCD Display
3.5" color TFT LCD screen with 320 x 240 resolution delivers clear visual output.

Waterproof Camera Probe
Compact 6mm probe is IP67-rated for water resistance and durability in harsh environments.

Integrated LED Lighting
Four built-in bright LEDs with a dimmer provide optimal illumination for dark or enclosed spaces.

Efficient Media Storage
Stores over 20,000 images on the included 4GB SD card and supports USB transfer.

Voice-Over Video Recording
Add audio commentary directly to videos for better inspection documentation.

AV Output Compatibility
Allows connection to external monitors for real-time viewing and presentations.

What's Included

Included with Your Purchase:

• 1 - Handset with Articulating Probe
• 1 - SD card
• 1 - 3.7V Rechargeable Battery
• 1 - Universal AC adaptor and multi-plugs (US, EU, UK, AUS)
• 1 - USB and AV cables
• 1 - Hard Carrying Case

Specifications

• Display Size: 3.5 inches (TFT LCD)
• Display Resolution: 320 x 240 pixels
• Camera Diameter: 6mm
• Probe Length: 1 meter (nondetachable)
• Articulation Range: 240°
• Lighting: 4 built-in LEDs with dimmer
• Storage Capacity: Over 20,000 images on included 4GB SD card
• Media Transfer: USB and SD card
• AV Output: Yes
• Audio Recording: Voice-over enabled in video mode
• Waterproof Rating: IP67 (camera probe only)
• Power Supply: 3.7V rechargeable battery and AC adapter with multi-plugs

FAQ

Q: Can the camera probe be detached?
A: No, the 6mm flexible probe is nondetachable.

Q: What is the articulation range of the camera tip?
A: The probe tip can be adjusted up to 240° for enhanced maneuverability.

Q: Does the unit record audio during video capture?
A: Yes, it supports voice-over audio recording.

Q: How is the lighting controlled?
A: The camera head has four LEDs with an integrated dimmer for adjustable brightness.

Q: Is it possible to view output on a larger screen?
A: Yes, the device includes an AV output for viewing images and video on an external monitor.
