The ANZZI SP-AZ048 is a VELD Series 64" full body shower panel system in clear white tempered Deco-Glass, combining a Heavy Rain overhead shower, two Acu-Stream body jets and ANZZI's Euro-Grip hand sprayer in one wall-hung tower. The panel hangs on brackets and connects to the supply lines already in the wall.
Rain, Jets and a Hand Sprayer
Stand under the swiveling crested Heavy Rain showerhead, 7.677" across, for a full rinse, or switch to the two Acu-Stream vector body jets, which provide a powerful water stream to massage the body. The Euro-Grip hand sprayer lifts off its holder on a free reign 60" reach. Flow is 1.8 GPM.
Two controls run everything: a thermostatic control for the water and a diverter that sends it to the head, the jets or the hand sprayer. The diverter gives a fully customizable shower experience.
Hangs on the Wall
The front panel is laser cut tempered glass in white, with a brass shower arm and flange, a stainless steel showerhead, a solid brass thermostatic valve and high grade ABS jets and hand shower. The panel weighs 26.84 lbs.
ANZZI's parts list spells out what each piece is made of: a stainless steel head shower, a brass arm bar and flange, a tempered glass front panel over a PVC backside body, zinc knobs, a brass handle and handle plate cover, a brass thermostatic faucet, ABS body jets and hand shower, and stainless steel braided and flexible hoses.
Mounting uses two brackets rather than an in-wall valve: first check that no hidden cables or pipes run where you will drill, then make two holes 1" apart for the top bracket at the height you want and two more 1" apart about 45" below for the bottom bracket, using a 6mm drill and the wall anchors. The hand shower holder goes through the pre-drilled hole in the panel with all O-rings in place, the shower arm fixes to the panel with a rubber washer and nut, and the panel's hot and cold hoses screw onto the 1/2" supply lines in the wall before the 62.99" tower is hung on the brackets.
The SP-AZ048 stands 62.99" tall and connects to 1/2" supply lines in the wall through flexible reinforced stainless steel hoses. ANZZI's other shower panel systems include the VISOR (SP-AZ035) in brushed steel, the MESA (SP-AZ043), the Niagara (SP-AZ023) and Arc (SP-AZ024) in brushed stainless steel, and glass panels such as the Melody (SP-AZ018), Pure (SP-AZ021) and Monsoon (SP-AZ012, SP-AZ012MB).
For a shower stall that needs a spa-style upgrade, the SP-AZ048 is an ANZZI 64" shower panel system with a Heavy Rain head, two Acu-Stream body jets, a 60" hand sprayer and a thermostatic valve, in clear white tempered glass.
Features
Heavy Rain Overhead Shower
The swiveling crested showerhead, 7.677" across, delivers ANZZI's Heavy Rain pattern for a full-body rinse you can angle.
Two Acu-Stream Body Jets
Two Acu-Stream vector massage body jet sets provide a powerful water stream to massage the body.
Euro-Grip Hand Sprayer, 60" Reach
The hand sprayer reaches 60" from the panel, which is built with a solid brass valve interior.
Thermostatic Control
ANZZI fits a solid brass thermostatic valve with its own thermostatic cartridge, controlled from the panel next to the diverter.
Diverter for Every Outlet
A separate diverter control switches water between head, jets and hand sprayer, giving a fully customizable shower experience.
Tempered Deco-Glass Panel
The laser cut white front is tempered Deco-Glass, over a solid brass valve interior and high grade ABS components.
Hangs on Brackets, 1/2" Supplies
The panel hangs on two wall brackets and connects to 1/2" supply lines with reinforced stainless steel hoses, so no wall rebuild is needed.
Specifications
-
Model: SP-AZ048
-
Height: 62.99"
-
Nominal Size: 64"
-
Weight: 26.84 lbs
-
Material: Tempered Deco-Glass panel; stainless steel showerhead; brass arm, flange and thermostatic valve; ABS jets and hand shower
-
Finish: Clear White
-
Installation: Wall mount on brackets
-
Controls: 2: thermostatic mixer and diverter
-
Showerhead: Heavy Rain, swiveling, 7.677" diameter
-
Body Jets: 2 Acu-Stream
-
Hand Sprayer: Euro-Grip, 60" reach
-
Flow Rate: 1.8 GPM
-
Supply Connection: 1/2", flexible reinforced stainless steel hoses
-
Valve: Thermostatic
-
Series: VELD
-
Warranty: Limited lifetime (register within 90 days)
What's Included
- SP-AZ048 VELD full body shower panel
- Heavy Rain shower head
- Two Acu-Stream body jet sets
- Euro-Grip hand sprayer with hose
- Mounting brackets with wall anchors and screws
- Owner's manual
Installation & Care
Installation
Wall mounted on two brackets: check for hidden cables and pipes, then drill two holes 1" apart (6mm drill) for the top bracket at the height you want and two more 1" apart about 45" below for the bottom bracket, and fix both with the wall anchors. Fit the hand shower holder and hose and the shower arm and head, screw the panel's hot and cold hoses onto the 1/2" supply lines in the wall, then hang the panel on the brackets and check for leaks.
Care
ANZZI's care guide: clean with regular soap and hot water on a non-abrasive cloth or sponge to stop build-up on the glass and fittings. Test any stronger cleaner on an inconspicuous area first, rinse every surface with water right after cleaning, and do not let the cleaner soak.
Resources
Shipping, Returns & Warranty
ANZZI ships this item from the SW Corp warehouse by UPS, FedEx or USPS, usually within 1 to 2 business days of your order. Shipping is free within the lower 48 states on orders of $101 or more (orders under $101 ship for a flat $15); for Alaska or Hawaii, contact us before you order. You'll get tracking by email as soon as it ships.
Inspect the packaging and the product before you sign. Note any damage or shortage on the delivery receipt, then email photos to support@mycleansupplies.com within 48 hours of delivery so the freight claim can be filed. Damage reported after 48 hours can't be claimed.
Unused ANZZI products in their original packaging can be returned within 21 days of delivery. Ask us for a return authorization before you ship. You pay the return shipping, which for a freight item means the freight cost, and a 20% restocking fee is deducted along with payment processing fees. Installed, used or damaged products and special-order items can't be returned.
ANZZI warrants this product to the original purchaser against defects in materials and workmanship for its lifetime, for residential use, and replaces a defective product or part free of charge. Register it at anzzi.com/register within 90 days of delivery to activate the warranty, and report any surface damage within 5 days of delivery, before installation. Shipping, handling and labor costs, commercial use, improper installation or maintenance, misuse, hard-water or mineral deposits and corrosive cleaners are not covered.
Warranty claims. Call ANZZI at 1-844-442-6994 (1-844-44-ANZZI) with your proof of purchase to submit a claim and get a return authorization (RMA). Register the product at anzzi.com/register within 90 days of delivery, or the warranty is not active. Contact us with your order number if you would like help with the claim.
About ANZZI
ANZZI is a kitchen and bath brand from SW Corp, a Miami, Florida company that also makes SteamSpa and MediTub. It designs freestanding and walk-in bathtubs, shower doors and bases, faucets, sinks, toilets and kitchen fixtures, bringing European bath design to North American homes.
The VELD is one of ANZZI's glass shower panel towers; others such as the Lann, Llano, Lynn and Melody panels offer different heights, finishes and jet counts.
